- Case Studies
- Thermal operating range of -15°C/+130°C
- Suitable for use in climate zone 1 and 2 (NZBC Climate Zones)
- High elasticity
- Excellent resistance to atmospheric ageing
- Excellent joint seal and adhesion to any type of approved substrate
- High resistance to mechanical and thermal stress
- Used for more than 40 years in more than thirty countries
- Compatible with EFVM testing.
BRANZ Appraisal No. 647 (2017)
The Allco Casali APP (Atactic Polypropylene) membrane system is suitable for a wide range of two-layer waterproofing applications for residential and commercial roofing. Approved for use as a waterproofing system under trafficable surfaces.
Suitable for use in climate zone 1 and 2 (NZBC Climate Zones) Casali APP membrane system has a high resistance to mechanical and thermal stress. Dermafil® has BRANZ certification and has been used for over 30 years in more than thirty countries all over the world.
The Allco Casali APP torch on membrane’s are installed as a two-layer system with:
- Dermaprimer solvent based primer. Low VOC options available on request.
- Olympia 3mm Base sheet (Aderix 2.5mm S/A base sheet for ALLTHERM/ALLRITE systems)
- Dermafil 4mm Cap sheet Finishes
- Olympia 3mm Base sheet - Sand
- Dermafil 4mm Cap sheet – Black, Grey (other colours available on request)
A bitumen-based compound modified with select polypropylene polymers (APP) and co-polymers, containing stabilised nonwoven polyester reinforcement.
A multi-functional system suited for a variety of applications, wide thermal operating range (-15°C/+130°C), adheres to different types of Allco approved substrates (reinforced concrete, plywood, roof cover boards.)
Displays consistent nominal thickness even after installation.
Laboratory Tested and Appraised by:
|Lab Test||Standard||u.m.||Dermabit Extra 30160 (Base)||Dermabit Extra 43170|
|Mass per unit area||EN 1849-1||kg/m²||3||5.2|
|Ultimate tensile strength|
|– Resistance at break – Longitudinal||EN 12311-1||N/5cm||700||850|
|– Resistance at break – Transversal||EN 12311-1||N/5cm||600||650|
|– Elongation at break – Longitudinal||EN 12311-1||%||40||40|
|– Elongation at break – Transversal||EN 12311-1||%||40||40|
|– Resistance at break – Longitudinal||EN 12310-1||N||150||170|
|– Resistance at break – Transversal||EN 12310-1||N||150||170|
|Flexibility at low temperatures||EN 1109||°C||-25||-20|
|Creeping at heat||EN 1110||°C||+150||+150|
|Thermal aging in air||EN 1296||∆ t°C||5||5|
|Reaction to fire||EN 13501-1||BS 476||F.AC Rating||F.AA Rating|
Due to the location of the building in the Wynyard Quarter there is a high concentration of contaminants, high water table and saline. A waterproofing membrane was required not only to handle hydrostatic pressure but also to act as a vapour barrier protecting indoor air from potential ingress of hydrocarbon vapours.
St Mary’s College
Tanking to footings and precast panel retaining walls, lift pit and storage areas, plaza deck, roof and gutters
Rose Garden Apartments
Tanking to footings and precast panel retaining walls, AFS walls, lift pit and storage areas, plaza deck, roof and gutters.
ASB Building - North Wharf
In the ASB project, Casali features across the roof expanse of buildings 22 and 23, including in roof gutters on external balconies and beneath timber decking. It is used in the landscaped area and external plant area and under parapets.
Sudima Hotel (Roofing)
The building of a 4.5-star environmentally friendly roof that would reflect the high New Zealand UV, provide a water collection option, not contaminate water going to storm water and provide a 20-year product and labour warranty.
