Features
Key Features
Guaranteed by more than 20 years of use in the field, covered by FLL-EN13948 certification, ecologically compatible – Eradix does not interfere with the growth of plants; easy to apply.
Lab Test | Standard | u.m. | Eradix 40200 |
Thickness | EN 1849-1 | mm | 4 |
Ultimate tensile strength | |||
– Resistance at break – Longitudinal | EN 12311-1 | N/5cm | 800 |
– Resistance at break – Transversal | EN 12311-1 | N/5cm | 800 |
– Elongation at break – Longitudinal | EN 12311-1 | % | 45 |
– Elongation at break – Transversal | EN 12311-1 | % | 45 |
Tearing Resistance | |||
– Resistance at break – Longitudinal | EN 12310-1 | N | 220 |
– Resistance at break – Transversal | EN 12310-1 | N | 240 |
Flexibility at low temperatures | EN 1109 | °C | -15 |
Creeping at heat | EN 1110 | °C | +130 |
Root Proof | EN 13948 | Pass |
Eradix is a special torch-on 10m² roll root-stop waterproofing membrane for multi-layer green roof solutions especially formulated to protect waterproofing systems from root damage.
The Eradix family of membranes comes from Casali’s research work on special chemical root-stop additives to attain products of absolute excellence for a wide range of project requirements (roof gardens, green roofs, flower beds, ground-laid structures of large and small surfaces).
The compound used in Eradix contains distilled bitumen modified with polypropylene polymer and the Bayer® additive Preventol® B2 which makes the compound an efficient and uniform chemical root-stop barrier, even along the membrane joints. Thanks to the use of reinforcement with high/medium mass per unit area consisting of continuous non-woven polyester, Eradix guarantees good mechanical performance for different types of stress (root pressure, weight of plants and soil, static loads, paths etc).
Top finish in branded polythene or natural slate chips disseminated uniformly and firmly anchored; smooth bottom finish in torched off branded polythene sheets.
Eradix is guaranteed by more than 20 years of use in the field, covered by FLL-EN13948 certification, ecologically compatible - it does not interfere with the growth of plants and is easy to be applied.

Antipodean Apartments
Recently completed, this substantial inner-city residential development encompasses 160 apartments over 14 levels in the vibrant heart of Auckland’s CBD.
Read More
ASB Building – North Wharf
In the ASB project, Casali features across the roof expanse of buildings 22 and 23
Read More
Auckland Central Library
Auckland Central Library Roof required the refurbishment of existing flat-roof and green-roof installation to preserve the building.
Read More
Auckland Zoo – East Asia Precinct
Auckland Zoo is the biggest Zoo in New Zealand. This project was apart of the Zoo’s 10-year re-development plan attempting to transform the zoo.
Read More

Crest Apartments
The mix development of commercial space, townhouses and 5 levels apartment tower required a robust system of waterproofing for exposed to rain areas at both ground retail level and elevated apartment tower balconies.
Read More
MacMurray Medical Centre
This cutting-edge private medical centre located in the Auckland suburb of Remuera was beautifully designed by Warren & Mahoney Architects to provide a relaxing patient experience, from the consultation suites to the operating rooms and recovery rooms.
Read More
Rangitoto Avenue House
Remuera House is a stunning residential property, Allco’s Casali Torch On Membrane was the preferred choice for the roofing solution.
Read More
Rose Garden Apartments
The Rose Garden Apartments, located at the heart of Auckland's North Shore, is an 800-apartment complex including a large basement garage.
Read More
St Cuthberts College – Tennis Courts
St Cuthbert’s College Tennis Courts was an addition to the school waterproofing installed by Sansom Construction Systems Ltd.
Read More
